IC5000L

  • IC5000L-Application-Guide
  • IC5000L-dim-diag
  • IC5000L-4
  • Lithium-technology
  • IC5000L-Application-Guide
  • IC5000L-dim-diag
  • IC5000L-4
  • Lithium-technology

Description

12V AUTOMATIC 50 AMP 5 STAGE LITHIUM BATTERY CHARGER   INSTRUCTION MANUAL Download PDF read more
Categories:
, ,
Brand:
Projecta
Type:

5 Stage Automatic

Input:

240VAC, 50Hz, 820W

Output:

12V

Output Current:

2, 6, 12, 25, 50A

Minimum Start Voltage:

1.0V

Back Drain:

Charger 1mA, with remote 2mA

Approvals:

Electrical Safety, EMC

Charge Voltage:

14.5V

Float:

13.5V

L.E.D. Charge Indication:

SCREEN – Back lit LCD screen

RED LIGHT ON – Power on

BLUE LIGHT ON -Charging

GREEN LIGHT ON – Fully charged and maintaining, no need to turn the charger off

Battery Charge Times:

IC5000L – DEEP CYCLE

VOLTAGE – 12V

BATTERY SIZE – 4–500Ah

CHARGE TIME – 2–10 hrs

Technical Advice

Compare

Description

12V AUTOMATIC 50 AMP 5 STAGE LITHIUM BATTERY CHARGER



INSTRUCTION MANUAL

Download PDF

Additional information

Type

5 Stage Automatic

Input

240VAC, 50Hz, 820W

Output

12V

Output Current

2, 6, 12, 25, 50A

Minimum Start Voltage

1.0V

Back Drain

Charger 1mA, with remote 2mA

Approvals

Electrical Safety, EMC

Charge Voltage

14.5V

Float

13.5V

L.E.D. Charge Indication

SCREEN – Back lit LCD screen

RED LIGHT ON – Power on

BLUE LIGHT ON -Charging

GREEN LIGHT ON – Fully charged and maintaining, no need to turn the charger off

Battery Charge Times

IC5000L – DEEP CYCLE

VOLTAGE – 12V

BATTERY SIZE – 4–500Ah

CHARGE TIME – 2–10 hrs
